ABICOR BINZEL MB EVO PRO 36
Description
Technical specification
ABICOR BINZEL MB EVO PRO 36 – air-cooled MIG/MAG welding torch
The ABICOR BINZEL MB EVO PRO 36 is a premium air-cooled MIG/MAG welding torch built for intensive industrial use. It features a robust 320 A rating with CO₂ and 290 A with mixed gas (M21), operating reliably at a 60% duty cycle under the DIN EN 60974-7 standard.
This torch stands out for its advanced ergonomics. BINZEL designed a two-component, tapered handle, a well-positioned trigger, and a ball-joint neck, enabling optimal control and reducing strain across all welding positions. The BIKOX® LW (lightweight) cable assembly shaves up to 34% off the torch weight, significantly easing operator fatigue and improving weld seam quality .
Durability gets special attention. BINZEL re-engineered the central connector and fittings for greater toughness while maintaining space in the handle to simplify maintenance. The internal structure promotes a cooler grip without sacrificing strength.
Compatibility is broad: the MB EVO PRO 36 accepts 0.8–1.2 mm wire and connects via Euro or DIN connectors, available in cable lengths of 3, 4, or 5 meters.
Ideal for tough shop environments—such as fabrication, heavy construction, shipbuilding, and industrial assembly—this torch combines performance, comfort, and longevity to give welders precision and power over prolonged shifts.
| Feature | Specification |
|---|---|
| Model | ABICOR BINZEL MB EVO PRO 36 |
| Cooling | Air‑cooled |
| Rated Current (CO₂) | 320 A (60% duty cycle) |
| Rated Current (M21) | 290 A (60% duty cycle) |
| Wire Diameter | 0.8–1.2 mm |
| Cable Assembly | BIKOX® LW (lightweight, up to –34% weight) |
| Handle | Two-component ergonomic with tapered grip |
| Neck | Ball-joint for flexible positioning |
| Connector | Robust central connector (Euro/DIN) |
| Duty Cycle | 60% |
| Cable Length Options | 3 m / 4 m / 5 m |
| Applications | Industrial MIG/MAG welding (fabrication, shipbuilding, heavy construction) |
