Technical specification
- For gripping, adjustment and assembly work in hard to reach areas thanks to slim, very long design
- Deep down situated parts can be easily reached using the slim, half-round tips
- Careful yet reliable gripping, holding and guiding of small copper pipes, screws and cables as well as other round parts thanks to milled grooves with smooth surfaces
- Serrated pipe grip to grip round parts
- Particularly suitable for work in the automotive trade and in mechanical engineering
- Slim yet robust tool
- Forged from special tool steel, oil-hardened and tempered
Article No. 28 71 280
EAN 4003773079415
Pliers black atramentized
Head polished
Handles plastic coated
Weight 235 g
Dimensions 280 x 55 x 14 mm
Standard DIN ISO 5745
REACH compliant does not contain SVHC
RoHS compliant not applicable
Jaw thickness (joint) (T1) 9.0 mm
Tips width (W4) 3.0 mm
Tips thickness (T2) 2.5 mm
Jaw length (L3) 76.5 mm
Head width (W3) 20.0 mm
For fitters and mechanics and for all purposes
Very long reach needle nose pliers with a ridged profile
Milled grooves with smooth surface and serrated pipe grip
Slim but at the same time very tough
