Pliers for Electrical Installation
Description
KNIPEX -13 82 200
Technical specification
- 6 functions in one pair of pliers
- Multifunctional pliers for the electrical installation; to grip flat and round material, for bending, deburring, cutting cable, stripping and crimping wire ferrules
- Smooth surfaces near the tips grip single cores without damaging them; serrated gripping surfaces and pipe grip for gripping flat and round material
- Clear-cut outside edge on the gripping surfaces for working on flush-mounted junction boxes and deburring feed-through holes
- Stripping holes for conductors of 0.75 – 1.5 mm² and 2.5 mm²
- Crimping die for wire ferrules 0.5 – 2.5 mm²
- Cable shears with (induction-hardened) precision cutting edges for copper and aluminium cables up to 5 x 2.5 mm² / Ø 15 mm
- Slim dimensions for easy access
- Bolted joint: precise, zero backlash operation of pliers
- High-grade special tool steel, forged, multi stage oil-hardened
- Article No. 13 82 200EAN 4003773075080Pliers black atramentizedHead polishedHandles with multi-component gripsWeight 280 gDimensions 200 x 85 x 20 mmREACH compliant does not contain SVHCRoHS compliant not applicableCutting capacity copper cable, multiple-stranded Ø 15 mmCutting capacity copper cable, multiple-stranded 50 mm²Stripping capacity for cross-sections 0.75 — 1.5 mm² / 2.5 mm²Capacity in square millimeters 0.5 — 2.5 mm²AWG 1 / 0
The multifunctional tool for electricians
For cutting cable, for wire stripping, deburring, bending, gripping and crimping
Due to their many functions, these universal pliers mean there is no need to constantly change tools. Just one tool is adequate for the most important, recurring work steps in electrical installation.Good ideas practically built in
The electrical installation pliers save time, space and weight. At 200 mm long, they fit in any tool bag and with a weight of just 280 g they are light weight – especially compared to a number of individual tools.Versatile tool for professional users
The tips of the gripping surface of the installation pliers are smooth, enabling single conductors to be held and positioned without damaging them. Profiled gripping surfaces and a pipe grip are provided for flat and round materials. The induction hardened precision cutting edges produce clean cut Cu and Al cables up to Ø 15 mm. Thanks to their non-slip multi-component grips, the installation pliers are safe and comfortable to use.
