BLACKBULL ARC-500

Category

Adopting advanced electronic IGBT & reliable controlling circuit, stable current and good welding performance.

Description

Adopting advanced electronic IGBT & reliable controlling circuit, stable current and good welding performance.
Deep bathe,stable arc,strong welding penetration and even long distance wellding.
Having selectable wire control mode on machine,can adjust welding current with remote control.
Suitable for every sort of rod (acid & alkali), as well cellulose rod.
Can save at least 30% energy compare to conventional welding machine.

Additional information

Specification

Name ; BLACKBULL Welding Machine Inverter DC (ARC-500IGBT)
SKU : ARC-500A-BB
Brand : BLACKBULL
Input Voltage : AC 380V 50/60Hz
Rated input capacity : 20Kw
No-load voltage : VRC 24V/WORKING 60V
Output current adjustment range : 500A
Rated duty cycle : 60%
No-load loss : 50W
Efficiency : 85%
Power factor : 93%
Arc force adjustment range : 0-100
Suitbale diameter of rod : Ø2.5-Ø6
Grow Weight : 20Kg
Machine Dimension : 470 x 240 x 430mm
Insulation class : F
Protection class : LP21
